Medium Size Most Efficient Air Source Heat Pump 4.5 - 20 KW Heating Capacity

WP Series air source heat pump unit for residential applications

SolarShine’s heat pump units are equipped by high standard and high quality components, which assure very high COP output and long-term service life.


WP series heat pump ranges from 3Hp-10Hp, with internal heat exchanger and water circulation design, suitable for large scale commercial water heating systems for hotel room, school dormitory, factory dormitory, hospital, etc.


SPEFICIATION DETAILS
Product typeWP series commercial heat pump main unit
ModelWP-S3.0WP-S5.0WP-S6.5WP-S10

Total

Power consumption

2.8KW1.32KW1.8KW2.2W
Compressor Power consumption2.71KW4.36KW5.75KW8.72KW
Nominal Heating capacity10.2KW16.48KW21.5KW32.6KW
COP of compressor (W/W)3.763.783.743.74
Ext. Dimension(mm)695x655x740706x686x9401450x705x1065
Circulation pumpExternal pump not included
Power supply220V/50hz380V/3N
Operation ambient Temperature0-45℃
Compressor brand/TypeHIGHLY /RotaryEmerson Copeland / scroll
RefrigerantR410A
Connection sizeDN25/ G1''DN40/ G1.5''

Loading Quantity of

1x20 container

60sets40sets40sets16sets

* The heating capacity and COP data is refer to testing lab under standard condition of ambient dry-bulb temperature 20℃, wet-bulb temperature 15℃, heating water from 15℃ to 55℃. COP is not a fixed value, but a dynamic data according to different climate and working condition.
