150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure

    Buy cheap 150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure from wholesalers

    Buy cheap 150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure from wholesalers
    • Buy cheap 150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure from wholesalers

    150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure

    Ask Lasest Price
    Brand Name : SolarShine/OEM/ODM
    Model Number : TH150-320L
    Certification : GB
    Supply Ability : 300 SETS per month
    • Product Details
    • Company Profile

    150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure

    Compact structure and good demonstrability

    Patented 100% titanium Heat exchanger in PVC & INOX Shell

    Intelligent Microcomputer controller

    High efficiency compressor with R410 refrigerant

    Air exchanger with hydrophilic coating

    Automatic defrosting function included

    Low noise.

    Simple installation

    Long lifespan

    Low operating cost

    less emissions than an oil boiler

    Designed and built especially for FAMILY sanitary hot water

    Suitable for hot water in operation throughout the year



    The most effective and safe water heating system...
    Get free hot water in sunny days.
    Use heat pump in rainy days, save 75% heating cost....
    The most effective and safe water heating system...


    SPECIFICATION DATA

    SERIESECO Series
    MODELHY-V-ECO-20T-1HY-V-ECO-24T-1HY-V-ECO-30T-1.5HY-V-ECO-36T-1.5
    Tank Capacity155L185L230L275L
    Vacuum tube quantity20PCS24PCS30PCS36PCS
    Solar vacuum tubeø58 x 1800mm/ high efficiency solar evacuated Tube,
    Inner tank materialSUS304 2B food-grade stainless steel / wall thickness =0.41mm
    Outer tank materialSUS304 2B food-grade stainless steel / wall thickness =0.31mm
    Water Tank ext sizeø450x1625mmø450x1925mmø450x2375mmø450x2825mm
    Insulation / thicknessHigh-density polyurethane foaming/45mm
    Frame material201# Stainless steel frame/ 30 x 60mm / 38o mounting degree
    Heat Pump TypeAir source heat pump (Water Pump Circulation Type)
    Heat pump operate power1KW/1Hp1KW/1Hp1.32KW/1.5Hp1.32KW/1.5Hp
    Heat pump heating power3.5KW3.5KW4.73KW4.73KW
    20 container quantity30 sets27 sets23 sets21 sets
    SERIESPLUS Series
    MODELHY-V-PlUS-20T-1HY-V-PLUS-24T-1HY-V--PLUS-30T-1.5HY-V-PLUS-36T-1.5
    Tank Capacity173L205L260L310L
    Vacuum tube quantity20PCS24PCS30PCS36PCS
    Solar vacuum tubeø58 x 1800mm/ high efficiency solar evacuated Tube,
    Inner tank materialSUS304 2B food-grade stainless steel / wall thickness =0.41mm
    Outer tank materialSUS304 2B food-grade stainless steel / wall thickness =0.31mm
    Water Tank ext sizeø500x1625mmø500x1925mmø500x2375mmø500x2825mm
    Insulation / thicknessHigh-density polyurethane foaming/60mm
    Frame materialAluminum alloy / 100CM width / 38o mounting degree
    Heat Pump TypeAir source heat pump (Water Pump Circulation Type)
    Heat pump operate power1KW/1Hp1.32KW/1.5Hp1.32KW/1.5Hp1.32KW/1.5Hp
    Heat pump heating power3.5KW4.73KW4.73KW4.73KW
    20 container quantity30 sets26 sets22 sets20 sets


    150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure

    150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure
    Successful applications:

    150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure

    Quality 150L / 260L / 320L Capacity Solar Heat Pump Water Heater 0.6 Mpa Working Pressure for sale
